17 Inch Panel Mount Touch Screen PC LCD Monitor Anti Shock Control Knob On Front Panel

Name: 17 Inch Panel Mount Touch Screen PC LCD Monitor Anti Shock Control Knob On Front Panel
Brand: ITD/OEM
Price: 1 USD

Wholesale 17 Inch Panel Mount Touch Screen PC LCD Monitor Anti Shock Control Knob On Front Panel from china suppliers

Brand Name : ITD/OEM

Model Number : ITD17PMT5MR1

Certification : CE/ROHS/FCC

Place of Origin : China

MOQ : 1PCS

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 10000 unit per month

Delivery Time : 10-15 work days

Packaging Details : Foam,gift box,master carton,wooden case,pallet

IP Rating : IP65 Front Panel

Touch Technology : Projected Capacitive Touch with 10 touch points/Resistive touch

Resolution : 1280 X 1024

Brightness : 250cd/m2

Port : USB/VGA/HDMI/Serial

Operating Temperature : -10~60℃ (-20~70℃ Optional)

Storage Temperature : 20~70℃

Mounting Method : VESA, embedded/panel mounting with clamps, desktop stand

MTBF : 50000H

Warranty : 1 Year for TFT panel and 2 years for internal electronics

Price : TBA

Contact Now

17 inch touch screen LCD monitor anti-shock&vibration brightness control knob on front panel for marine

ITD rugged industrial Flush/Panel Mount displays are fully-integrated in an industrial-grade IP65/ NEMA 4-4x ingress rating for front panel and HMI interface provide a full range of industrial-grade units with multi-function capabilities and brilliant displays. The flush mount display can be directly connected to industrial processing machines, control systems, automation systems, and especially marine application.

SPECIFICATION

Model	ITD10PMT5MR1	ITD12PMT5MR1	ITD15PMT5MR1	ITD17PMT5MR1	ITD19PMT5MR1	ITD21PMT5MR1	ITD24PMT5MR1
Size	10.4”	12.1”	15”	17”	19"	21.5"	24"
Active Area(mm)	211.2 x158.4	246.0x184.5	304.12x228.09	337.92x270.33	376.32x301.06	476.64x268.11	531.36x298.89
Contrast Ratio	500:1	500:1	700:1	1000:1	1000:1	1000:1	1000:1
Resolution	800 x 600	800 x 600	1024 x 768	1280 x 1024	1280 x 1024	1920 x 1080	1920 x 1080
Brightness	300nits	300nits	250nits	250nits	250nits	250nits	300nits
Viewing Angles	70/70/60/70	70/70/60/60	80/80/60/70	85/85/80/80	85/85/80/80	85/85/80/80 or 89/89/89/89	85/85/80/80 or 89/89/89/89
Backlight	LED	LED	LED	LED	LED	LED	LED

SPECIFICATION

Input Signal Connectors	VGA, DVI, HDMI
Power Input	DC 9~36V Power Supply
Operating Temperature	-10~60℃
Storage Temperature	-20~70℃
Operating Humidity	5%~95% (non condensing)
Anti-Vibration	5Hz-500Hz / 1Grms/3 Axis
Anti-Shock	15G, 15ms duration
User Control	Power on/off via Front Button; Power Mode Status LED; On Screen Display Control
Order Information	Marine LCD Monitor with Resistive Touch/ITD**PMT1MR1
	Marine LCD Monitor with PCAP Touch/ITD**PMT5MR1
	Marine LCD Monitor with Tempered Glass/ITD**PMG1MR1
	Marine LCD Monitor with AR Tempered Glass/ITD**PMG2MR1

FEATURES

• Dimming control backlight brightness from nearly 0% to 100%

• 9 to 36V DC wide voltage power input acceptable

• Ease of use front panel OSD control

• Enhanced shock and vibration resistance

• Ruggedized levels of NEMA 4, IP65 for front panel

• Aluminum front bezel and steel chassis construction designed for harsh and industrial environments

▪ CE, FCC, RoHS Compliance

OPTIONALS

Resistive Touch Screen, PCAP Touch Screen, AR Protective Glass, Optical Bonding
VESA Mounting Brackets or Desktop Stand
S-Video, Composit inputs
RS232 Remote Control
Dimming Knob on Front

Product Display:

17 Inch Panel Mount Touch Screen PC LCD Monitor Anti Shock Control Knob On Front Panel

17 Inch Panel Mount Touch Screen PC LCD Monitor Anti Shock Control Knob On Front Panel

Applications:

17 Inch Panel Mount Touch Screen PC LCD Monitor Anti Shock Control Knob On Front Panel
